Thickness Measuring Microscope
Quantity: In Stock
Category: Manual Measuring Equipment
Business & Industrial > Science & Laboratory > Laboratory Equipment > Microscopes
Quick Overview:
Equipment : Thickness Measuring Microscope
Brand : Union Optical, Japan
P/N : THS10. THS20,THS30
An unique microscope for direct Non-contact thickness measurement with Top and Bottom objective lens.
Non-contact real thickness measurement in seconds. No flipping of workpiece.
Brand : Union Optical, Japan
P/N : THS10. THS20,THS30
An unique microscope for direct Non-contact thickness measurement with Top and Bottom objective lens.
Non-contact real thickness measurement in seconds. No flipping of workpiece.
Share:
- A unique measuring microscope with one objective above the measuring stage like any conventional measuring microscope and another objective installed below the measuring stage.
- The upper objective is for normal XYZ measurement and once the lower objective is used together with the upper objective, it can give an instant thickness measurement.
- Thickness Measurement with no sample flipping
- Resolution : 1um, 0.5um, 0.1um
- Stage travel : 100 x 100mm, 200x200mm and 300x300mm
- Focus indicator and verification kits included.
- Objective : 10x, 20x, 40x, 100x objective
Sorry, Currently No Video Uploaded.
Sorry, Currently No File Uploaded.
Thickness Measuring Microscope
Please Leave Your Product Enquiry Here. We will Get Back To You Soon.
Product Specifications
- Product SKU : -
- Weight (GRAM) : -
- Dimension : -
